It adopts a 32-bit high-speed MCU data processing + 24-bit high-speed AD measurement chip, featuring fast response speed, high precision, and stable reliability

Multi-interface display, including file list, real-time list display, bar chart display, real-time/record/analysis curve display, alarm list, system Settings, etc

Basic measurement accuracy: 0.2℃+2 digits (excluding sensor), cold end compensation accuracy: 0.5℃

Independent error correction for each channel Y=KX+B.

You can customize the name of each channel and export the name to EXCEL

A 5-inch high-definition IPS industrial-grade LCD touch screen with a high resolution of 854X480, providing clearer display

It adopts a 32-bit high-speed MCU data processing + 24-bit high-speed AD measurement chip, featuring fast response speed, high precision, and stable reliability

Multi-interface display, including file list, real-time/record/analysis list display, alarm list, system Settings, etc

Supports multiple sensor inputs: KJETNSRB

Basic measurement accuracy: 0.2℃+2 digits (excluding sensor), cold end compensation accuracy: 0.5℃

Independent error correction for each channel Y=KX+B

It adopts a 32-bit MCU design, ensuring more accurate measurement and faster, more stable sampling speed

The voltage difference between channels can be as high as AC/DC350V, with an extremely strong anti-interference capability

Each module has 8 channels, and this machine supports up to 32 channels at most, which can be freely expanded

Each channel has an independent temperature correction △ value and cold end value correction

Each channel can independently set alarm values for both excessively high and low levels, with multiple alarm prompts: LL(extremely low), L(too low), H(excessively high), HH(extremely high), and is equipped with relay output

It is equipped with 8GB of super large memory, capable of recording up to 32 files, with each file capable of recording 60,000 sets of data, and supports local query of historical curves

It adopts a 32-bit MCU design, ensuring more accurate measurement and faster, more stable sampling speed

The voltage difference between channels can be as high as AC/DC350V, with an extremely strong anti-interference capability

Each module has 8 channels, and this machine supports up to 64 channels at most, which can be freely expanded

Each channel has an independent temperature correction △ value and cold end value correction

Each channel can independently set high and low alarm values and has sound and light alarm functions. It is equipped with 8G of large built-in memory, which can record up to 32 files, and each file can record 60,000 sets of data

It is equipped with a USB flash drive interface, supporting the download and copy of records via a USB flash drive, as well as offline saving, making it more convenient to use

It adopts a 4.3-inch industrial true-color display LCD screen, featuring clear pictures, brilliant colors and wide viewing angles

Supports real-time curve and bar chart display

The voltage difference between channels can be as high as AC/DC 350V, with an extremely strong anti-interference capability

Built-in memory, capable of recording up to 8 files, with each file capable of recording 130,000 sets of data

It is equipped with a USB flash drive interface, supporting the download and copy of records via a USB flash drive, as well as offline saving, making it more convenient to use
